GTO(gate turn-off thyristor) modules A1, A2, A3. GTOs convert the the current from the DC link to VVVF(Variable Voltage variable frequency) 3 phase AC. Note the 3 fat wires on the left leading from the GTO's to the traction motors.

Date: 2008-01-18
Owner: Jay Balakrishna
