A close up of the slide valve control gear. There are two cylinders on each side. The upper one runs the pinion and the lower one the wheels. The upper cylinder can rotate the rack even when the loco is stationed on a track without the rack.

Date: 2007-05-10
Owner: Zubin J Dotivala
Size:
Full size: 1280x960
