Gallery Diesel and Electric Locomotives Electric Locomotives WAP-4 and Variants Relay Q20 setting in AJJ WAP4

The setting of the Traction Motor Overvoltage relay is shown in the cab of an Arrakkonam WAP4.It is supposed to sound an audible alarm when the voltages reaches 865 volts and in some locos this also triggers auto-regression till the voltage drops below the limit. (Khalid Kagzi)
